The 2025 Ford Super Duty® in Shaker Heights, OH
Built to take on the toughest jobs, the 2025 Ford Super Duty® is your ultimate partner for power, performance, and precision. From towing heavy loads and hauling gear to tackling demanding terrain, this truck is ready for it all. Explore the impressive engine options, towing specs, and work-ready features that set the 2025 Super Duty® apart.
Engine Options Built for Demanding Work
The 6.8L V8 gas engine generates 405 horsepower at 5,000 rpm and 445 lb.-ft. of torque at 4,000 rpm. The 7.3L V8 gas engine increases output to 430 horsepower at 5,500 rpm and 485 lb.-ft. of torque at 4,000 rpm. The 6.7L Power Stroke® V8 Turbo Diesel produces 475 horsepower at 2,600 rpm and 1,050 lb.-ft. of torque at 1,600 rpm. The 6.7L High-Output Power Stroke® V8 raises performance to 500 horsepower and 1,200 lb.-ft. of torque.
All engines pair with a 10-speed TorqShift® automatic transmission. The 6.8L gas engine uses the TorqShift®-G version, which includes selectable drive modes for Normal, Tow/Haul, Eco, and Slippery conditions. Transmission cases are aluminum. Gear ratios range from 4.696:1 in first gear to 0.632:1 in tenth. Reverse gear ratios vary from -4.695:1 to -4.866:1, depending on setup. Power takeoff access is standard on the driver side.
Dimensions Built for the Job Site
Regular Cab, SuperCab, and Crew Cab options are available. Wheelbase lengths range from 141.4 inches to 175.9 inches. Overall lengths span from 231.8 inches to 266.2 inches. Vehicle height varies by trim. F-250® SRW models stand between 78.9 and 81.6 inches tall. F-450® DRW models reach up to 82.1 inches. Width without mirrors is 80 inches for SRW and 96 inches for DRW. Width with mirrors measures 105.9 inches across the board.
Ground clearance on F-250® SRW models reaches 10.2 inches. F-350® and F-450® models provide up to 10.6 inches. Approach angles reach up to 27.7 degrees. Departure angles go as high as 21.5 degrees. Ramp breakover angles vary by suspension, with a maximum of 25.4 degrees.
Towing and Payload That Meet Your Demands
Conventional towing capacity reaches 30,000 pounds with specific F-250® setups. Fifth-wheel towing goes up to 38,000 pounds when properly equipped. Gooseneck towing maxes out at 40,000 pounds in F-450® DRW models powered by the 6.7L HO diesel engine. Gross Combined Weight Ratings reach 48,000 pounds. Payload capacity surpasses 4,200 pounds in certain F-250® models. F-350® and F-450® models deliver comparable payloads with proper equipment.
Chassis, Suspension, and Braking Built for Strength
Front suspension systems include a mono-beam design with coil springs, gas shocks, and a stabilizer bar. F-450® models use a wide-track front suspension. Rear suspension features solid axles with leaf springs. Maximum front Gross Axle Weight Ratings range from 5,000 to 5,600 pounds. Rear GAWR peaks at 10,300 pounds for F-350® DRW and 9,900 pounds for F-450®.
Braking systems include 4-wheel vented disc brakes with ABS. Front rotors reach 15.39 inches on F-450® models. Rear rotors measure up to 15.75 inches. Hydraulic power assist enhances steering control under load.
Wheels and Tires Configured for Every Job
Wheel options include 17-inch, 18-inch, and 20-inch sizes on SRW trucks. DRW configurations use 17-inch wheels on F-350® and 19.5-inch wheels on F-450®. Bolt patterns vary by axle: 170 mm (8-lug) for SRW, 200 mm for F-350® DRW, and 225 mm (10-lug) for F-450®.
Cab Options with Practical Space
Regular Cab models provide 40.8 inches of headroom, 66.7 inches of shoulder room, and 43.9 inches of legroom. SuperCab and Crew Cab configurations offer up to 40.4 inches of rear headroom and 43.6 inches of rear legroom. Crew Cab models provide 131.9 cubic feet of passenger volume. Behind the first row, cargo space measures 53.4 cubic feet.
Cargo Beds Ready for Work
Cargo bed lengths include a 6.75-foot and an 8-foot option. The 6.75-foot bed offers 81.9 inches of floor length and 65.4 cubic feet of volume. The 8-foot bed extends to 98.1 inches with 78.5 cubic feet of storage. Both beds have a 66.9-inch maximum width and 50.5 inches between wheelhouses. Tailgate openings measure 60.5 inches wide.
Fuel Capacity That Supports Long Days
Fuel tank sizes range from 29 to 48 gallons. Gas engines offer 34- and 48-gallon options. Diesel variants use 29-gallon tanks on shorter wheelbases and up to 48 gallons on long wheelbase Crew Cab models.
Electrical Systems Built for Demands
Alternator output ranges from 160 to 250 amps on XL through Platinum trims. Limited models include a 352-amp alternator. Gas engines use a single 12-volt battery rated at 650–750 cold-cranking amps. Diesel engines use dual 12-volt batteries. All engines include a pressurized series-flow cooling system and are equipped with either an Oil Life Monitor® or an Intelligent Oil Life Monitor® for maintenance tracking.
Drivetrain and Axle Options for All Terrain Types
All models are available in 4x2 and 4x4 configurations. Axle ratios include 3.31, 3.55, 3.73, 4.10, and 4.30. An available electronic locking rear axle boosts traction when needed. The Tremor® Off-Road Package enhances off-road performance with specialized tuning and hardware.
